JORC
1613 JORC FLUIDRAIN-S G1/2 4.5 V 230VAC
2 936,07
SEK
Beställningsvara
Kategorier:
Condensate drain
Manufacturer: JORC
Specifikationer
- Ambient temperature
- +1°C to +55°C
- Test function
- Yes
- Clock generator
- PCB/SMD technology ensures consistency of production
- Inlet height [mm]
- 10
- Nominal voltage
- 230 VAC
- Cycle display Clock generator
- Bright LED lighting
- Maintainable valve
- Yes
- Protection class
- IP65 (NEMA4)
- Max. compressor capacity
- Unlimited
- Medium temperature
- +1°C to +55°C
- Zeitzyklus (On/Off)
- 0.5 - 10 sec / 0.5 - 45 min
- Plug connection
- DIN 43650-A
- Bemerkung
- Stainless Steel Timed Steam Trap for High Pressure
- Ventil Nennweite
- depending on the pressure area
- System pressure
- 0 to 500 bar (depending on the FLUIDRAIN model)
- Valve housing material
- Brass or stainless steel valve, depending on pressure range
- Valve type
- 2/2-way, directly controlled
- Outlet connection
- 1/2" (BSP or NPT)
- Inlet connection
- 1/2" (BSP oder NPT)
