1931 XP JORC FLUIDRAIN-S400 G1/4 115VAC

Specifikationer

Zeitzyklus (On/Off)

0.5 - 10 sec / 0.5 - 45 min

Ambient temperature

+1°C to +55°C

Test function

Yes

Clock generator

PCB/SMD technology ensures consistency of production

Inlet height [mm]

10

Outlet connection

1/4" (BSP or NPT)

Plug connection

DIN 43650-A

Cycle display Clock generator

Bright LED lighting

System pressure

0 to 500 bar (depending on the FLUIDRAIN model)

Protection class

IP65 (NEMA4)

Valve housing material

Brass or stainless steel valve, depending on pressure range

Bemerkung

Stainless Steel Timed Steam Trap for High Pressure

Valve type

2/2-way, directly controlled

Max. compressor capacity

Unlimited

Medium temperature

+1°C to +55°C

Inlet connection

1/4" (BSP or NPT)

Ventil Nennweite

depending on the pressure area

Nominal voltage

115 VAC
