- Ambient temperature
- +1°C to +55°C
- Test function
- Yes
- Clock generator
- PCB/SMD technology ensures consistency of production
- Inlet height [mm]
- 10
- Plug connection
- DIN 43650-A
- Protection class
- IP65 (NEMA4)
- Max. compressor capacity
- Unlimited
- Medium temperature
- +1°C to +55°C
- Nominal voltage
- 115 VAC
- Valve type
- 2/2 way, directly controlled
- Valve seal
- FPM
- Ventil Nennweite
- 4 mm
- Maintainable valve
- Yes
- System pressure
- 0 to 16 bar
- Inlet connection
- 1/4" & 1/2" (BSP or NPT) / 1/2" (BSP or NPT)
- Outlet connection
- 1/4" & 1/2" (BSP or NPT) / 1/2" (BSP or NPT)
- Bemerkung
- Digital and timed steam trap
- Cycle display Clock generator
- bright LED lighting and LED display
- Valve housing material
- Brass (Stainless Steel Available, see FLUIDRAIN)
- Zeitzyklus (On/Off)
- 0.01 seconds up to 99 hours (for On and Off)
